CNC-5000 Vertical Machining Center
The CNC-5000 is our flagship 5-axis vertical machining center, featuring high-speed spindle technology and advanced thermal compensation for exceptional precision in complex part manufacturing.
Email:sales@example.com
Tel:+86 1234567890
Key Features
- 5-axis simultaneous machining capability
- High-speed spindle: 15,000 RPM with HSK-A63 interface
- Advanced thermal compensation system
- Integrated tool magazine: 60 tools standard
- Linear glass scales on all axes
- Fanuc 31i-B5 CNC control system
Technical Specifications
| X/Y/Z Travel | 1000 x 600 x 600 mm |
| Table Size | 800 x 500 mm |
| Max Table Load | 800 kg |
| Spindle Speed | 50-15,000 RPM |
| Spindle Power | 22 kW |
| Positioning Accuracy | ±0.005 mm |
| Repeatability | ±0.002 mm |
